#31

Open Discussion / Re: The secret M117 flanger

Last post by Scruffie - June 04, 2026, 06:07:37 PM

There are two 4013s in the pedal, each with two flip flops. One of the 4013s dedicates one flip flop to each of the MN3004s to make the biphase clock pulses so each MN3004 has its own driver. Im honestly not sure this is even necessary considering the clock freqs (13KHz to 500KHz), which are roughly halved compared to an SAD1024 unit or generally any Panasonic BBD equipped flanger pedal. The other 4013 is the oscillator. Of the 4 flip flops available, I believe 3 are used.

I was reading the old schem wrong about the BBDs being in parallel. The input pins of the two MN3004s are connected in my unit and the clock phases are matched which IIRC is the differential operation shown in the SAD1024 datasheet. Maybe the folks at MXR looked at the performance of the Panasonic BBDs and traded super short delay times for better performance with differential configuration? The sound of the pedal is spectacular. Better than an SAD1024 MXR IMO.

The only DIY project I have seen that offered these alternate BBD configurations is the BYOC flanger, but Im pretty sure they were running parallel multiplex and calling it differential.

Side note - The lag here is like an hour or two for posts to appear. Never experienced that on another simple machines forum.

Thanks for that, so it's just using one half of each CD4013? What an odd design choice... Definitely not using the chip handling oscillator division in parallel? That might make a little more sense in lieu of a clock buffer, given the BBD's have equal clock capacitance to an MN3007.

The BBD's were in series in the original which it did look like was the direction it was heading in the gut shots Jessenator sent me, is parallel confirmed?

Are you able to measure the clock frequencies as well out of interest?

If someone posts some decent gut shots it shouldn't be too hard to trace and confirm seeing as we already have the 117 schematic.

I'll PM you. Let me know if you need different angles than what I captured.

Thanks, unfortunately to get a good look at the traces you'd need to unsolder the pots.

But, I thought of a much simpler solution... just test for continuity between pin 2 of both MN3004, if it beeps, they share the same clock.

If it doesn't beep, check pin 2 of one doesn't match to pin 12 of the other.

Still no beep? Then it's time to test the CD4013 for continuity.

Probed around in mine. One half of the inner 4013 handles generating the two phase pulses for each MN3004. The  outer 4013 is then the other half of the clock circuit although I believe based on photos earlier in the thread that there is a single oscillator feeding the two flipflops. BBDs are in parallel like the original design.

Ahhh, this is making much more sense, so they've parallel multiplexed (I assume unless there's an extra op-amp to achieve differential operation) and halved the clock to achieve the same delay times as the original probably, as you note regards SAD vs. Panasonic, to avoid the MN3004's heavy signal drop off at those higher clock frequencies and also so there's not a heavier high frequency roll off from running them in series.

No, parallel clocks was probably a little overkill but suppose it doesn't hurt, especially with the longer clock traces.

Also helps makes sense as to why the later version just uses a single MN3204 but with heavier noise reduction circuitry.

Think the mystery is solved, still, might be interesting to trace and see if there was any other alterations to the circuit... I do notice an extra diode in the astable section area.

Yeah, the forum does appear to be having some issues, there's a note on the homepage up at the top right.

#32

Open Discussion / Re: The secret M117 flanger

Last post by museums - June 04, 2026, 03:13:33 PM

There are two 4013s in the pedal, each with two flip flops. One of the 4013s dedicates one flip flop to each of the MN3004s to make the biphase clock pulses so each MN3004 has its own driver. Im honestly not sure this is even necessary considering the clock freqs (13KHz to 500KHz), which are roughly halved compared to an SAD1024 unit or generally any Panasonic BBD equipped flanger pedal. The other 4013 is the oscillator. Of the 4 flip flops available, I believe 3 are used.

I was reading the old schem wrong about the BBDs being in parallel. The input pins of the two MN3004s are connected in my unit and the clock phases are matched which IIRC is the differential operation shown in the SAD1024 datasheet. Maybe the folks at MXR looked at the performance of the Panasonic BBDs and traded super short delay times for better performance with differential configuration? The sound of the pedal is spectacular. Better than an SAD1024 MXR IMO.

The only DIY project I have seen that offered these alternate BBD configurations is the BYOC flanger, but Im pretty sure they were running parallel multiplex and calling it differential.

Side note - The lag here is like an hour or two for posts to appear. Never experienced that on another simple machines forum.

Thanks for that, so it's just using one half of each CD4013? What an odd design choice... Definitely not using the chip handling oscillator division in parallel? That might make a little more sense in lieu of a clock buffer, given the BBD's have equal clock capacitance to an MN3007.

The BBD's were in series in the original which it did look like was the direction it was heading in the gut shots Jessenator sent me, is parallel confirmed?

Are you able to measure the clock frequencies as well out of interest?

If someone posts some decent gut shots it shouldn't be too hard to trace and confirm seeing as we already have the 117 schematic.

I'll PM you. Let me know if you need different angles than what I captured.

Thanks, unfortunately to get a good look at the traces you'd need to unsolder the pots.

But, I thought of a much simpler solution... just test for continuity between pin 2 of both MN3004, if it beeps, they share the same clock.

If it doesn't beep, check pin 2 of one doesn't match to pin 12 of the other.

Still no beep? Then it's time to test the CD4013 for continuity.

Probed around in mine. One half of the inner 4013 handles generating the two phase pulses for each MN3004. The  outer 4013 is then the other half of the clock circuit although I believe based on photos earlier in the thread that there is a single oscillator feeding the two flipflops. BBDs are in parallel like the original design.

#33

Build Reports / Re: Polyphemus [One Knob Overd...

Last post by Devinimpson - June 04, 2026, 09:15:43 AM

This all started with Jessenator giving me the bullying me for building in 125B instead of 1590B. I threatened to put a mosfet boost in a 1590XX just to spite him. That's not where I ended up, but the idea for this circuit did come to me while contemplating mosfets and revenge.



Polyphemus is a one-knob overdrive/distortion with internal voicing options that allow it to be tailored to a variety of rigs and use cases. The idea was, to do all the dialing in up front, then screw the thing shut and just rock! As it's built around a Super Hard On of sorts, it only seemed appropriate to name it after the original one-eyed monster!



The circuit consists of three gain/eq stages. The first stage is a high shelf filter that boosts everything above a set frequency by 20dB. Everything below that frequency stays at unity gain. The second stage is a simple mosfet boost, which is pushed by the first stage into clipping. The final stage is a low shelf, set at a similar frequency to the first. This flattens out the eq again. This makes for a "transparent" overdrive that emphasizes harmonics and retains clarity, since higher frequencies are saturated more and sooner. It also greatly lowers the noise floor!



Switches 1 and 2 set the capacitance/cut-off frequency in the HPF stage. Switches 3 and 4 set the capacitance/cut-off frequency in the LPF stage. HPF and LPF interact to shape the character of the gain, as well as the frequency response. Flat, transparent overdrive, various kinds of mid boost or treble boost, mid scoop, even distortion/fuzz is achievable. Heat sets the range of the Gain control. This is so that the headroom can be adjusted to suit your pickups and maximize the range of the Gain Control. Output is a volume control. With Heat dialed in, there is a moderate change in volume from the lowest to the highest Gain setting (maybe 6dB). I like to set Output so that the lowest Gain setting is about unity with bypass, but you could attenuate or boost to taste.
